Commissioning
4.6 Alternatively: Creating a project with a device configuration derived from the hardware
Commissioning with Startdrive
Commissioning Manual, 11/2017, 6SL3097-4AA10-0BP1
159
Transferring the determined device configuration to Startdrive
Note
Overwriting existing data in the device configuration
If components already exist in the device confi
guration of the drive unit from which you
started discovery of the device configuration, they will be deleted or overwritten when data
are created by the automatic configuration.
Creating the component topology in Startdrive
After you have checked and, if required, corrected the topology determined in the
configuration, you can transfer this topology to a Startdrive project.
1. Make sure that there are no non-assignable components in the "Device configuration
detection" dialog.
Only when there are no non-assignable components is the "Create" button active.
2. Click the "Create" button.
