Siemens SIROTEC Commissioning Manual

Diagnostics
5.2 Diagnostics using LEDs
Commissioning with Startdrive
Commissioning Manual, 11/2017, 6SL3097-4AA10-0BP1
321
5.2.3
Additional modules
5.2.3.1
Control Supply Module
Table 5- 20 Control Supply Module – description of the LEDs
LED
Color
State
Description, cause
Remedy
READY – off Electronic power supply is missing or outside permissible
tolerance range.
–
Green Continuous
light
Component is ready to operate. –
DC LINK – off Electronic power supply is missing or outside permissible
tolerance range.
–
Orange Continuous
light
DC link voltage within permissible tolerance range. –
Red Continuous
light
DC link voltage outside permissible tolerance range. –
5.2.3.2
SMC10/SMC20 Sensor Module Cabinet
Table 5- 21 Sensor Module Cabinet 10/20 (SMC10/SMC20) – description of the LEDs
LED
Color
State
Description, cause
Remedy
RDY
READY
– off Electronic power supply is missing or outside permissible
tolerance range.
–
Green Continuous
light
The component is ready for operation and cyclic DRIVE-
CLiQ communication is taking place.
–
Orange Continuous
light
DRIVE-CLiQ communication is being established. –
Red Continuous
light
At least one fault is present in this component.
Note:
LED is controlled irrespective of the corresponding mes-
sages being reconfigured.
Remedy and
acknowledge fault
Green/red Flashing
light 0.5 Hz
Firmware is being downloaded. –
Flashing
light 2 Hz
Firmware download is complete. Wait for POWER ON Carry out a POWER
ON
Green/
orange
or
Red/
orange
Flashing
light
Component recognition via LED is activated (p0144).
Note:
Both options depend on the LED status when module
recognition is activated via p0144 = 1.
–
