Appendix
A.4 Shortcut menus and icons in Startdrive
Commissioning with Startdrive
390 Commissioning Manual, 11/2017, 6SL3097-4AA10-0BP1
Button
Description
"Show signal
name"
Display of the signal names
If the check box is selected, the signal names in the formula are displayed in-
stead of the signal references.
"Validate" Check the validity of the formula
"Result of valida-
tion"
Result of validation
Displays the result of the validation and indicates errors and error locations.
"OK"
Transfer the entries in the formula editor
"Cancel"
Discard the entries in the formula editor
A.4.3
BICO interconnections
The following icons are used for BICO interconnections:
Icon
Meaning
Allows the BICO interconnection of a binector input. The interconnection
dialog is opened by clicking on the icon.
Allows the BICO interconnection of a binector output. The interconnection
dialog is opened by clicking on the icon.
Allows the BICO interconnection of a connector input. The interconnection
dialog is opened by clicking on the icon.
Allows the BICO interconnection of a connector output. The interconnec-
tion dialog is opened by clicking on the icon.
Clicking on the icon next to the interconnection field allows a list of all of
the active interconnections of the parameter to be opened/displayed.
Shows that invalid BICO wiring exists in the drive screen forms.
