A.4 Shortcut menus and icons in Startdrive
Commissioning with Startdrive
382 Commissioning Manual, 11/2017, 6SL3097-4AA10-0BP1
A.4
Shortcut menus and icons in Startdrive
A.4.1
Function calls project view
A.4.1.1
Project navigation
Shortcut menu
The shortcut menu of a drive in the project navigator contains the following entries:
Menu item
Icon (button) in the toolbar
Description
Open
-
Opens the drive device view.
Parameters - Opens the parameter view in the working area.
Cut Cuts the selected content and copies it to the clipboard.
Copy
Copies the content to the clipboard.
Paste Inserts the clipboard content into the project navigation.
Delete
-
Deletes the selected content from the project navigation.
Rename
-
Permits a designation to be changed.
Go to topology view - Opens the topology view for drives that are networked via
PROFINET.
Go to network view
-
Opens the network view.
Download to device Loads the data from the project into the drive (only when online).
Upload from device
(software)
Loads the data from the device into the project (only when online).
Compile
-
Compiles existing programs.
Go online Establishes an online connection to the drive.
Go offline Disconnects the online connection - the drive goes offline.
Online & diagnostics - Opens the Online & diagnostics editor; if the drive is not online,
Startdrive tries to establish an online connection.
Browsing a project
Opens a search mask You can browse for individual information
about the active project using this mask.
Properties - Opens the Properties dialog of the drive. There, for example you set
bus parameters.
