Siemens SIROTEC Commissioning Manual

Diagnostics
5.3 Diagnostics via Startdrive
Commissioning with Startdrive
346 Commissioning Manual, 11/2017, 6SL3097-4AA10-0BP1
Activating the trace recording
Proceed as follows to activate the trace recording in the drive:
1. Click on icon
.
The trace is activated in the drive and starts the recording corresponding to the
configured trigger condition.
The current status of the recording is displayed in the status display of the trace.
Note
When a recording is restarted, the previously recorded values are lost.
To save the values that have been recorded, save the mea
surement in the project (see
Chapter "
Saving measurements in the project (Page 347)"), before you reactivate the
recording.
Deactivating the trace recording
Proceed as follows to exit the activated trace recording in the drive:
1. Click on icon
.
The trace is deactivated in the drive.
The status display of the trace changes to "Inactive".
5.3.2.6
Displaying the trace recording
Requirement
● An online connection has been established to the drive.
● A recorded trace is saved in the drive.
Or:
● A measurement is in the "Measurements" system folder.
Procedure
To display the recording, proceed as follows:
1. Select a trace in the drive.
2. Double-click the selected trace.
3. If required, activate the icon
for monitoring.
4. Check to ensure that the signals (
) are shown in the "Diagram" tab in the signal table.
You can display the signals via the shortcut menu.
