4.4 Creating a project offline in Startdrive
Commissioning with Startdrive
Commissioning Manual, 11/2017, 6SL3097-4AA10-0BP1
91
Inserting an infeed unit
4.4.4.1
Inserting a space holder for an infeed unit
Requirement
● A project has been created.
● The Control Unit is inserted in the device configuration.
Note
Sequence
Generally, the infeed is inserted in the configuration immediately after the drive in the device
view. In this case, the infeed is also automatically wired to the
drive (X100).
You can also insert an infeed at a later point in time (for example, after the Motor Module).
The infeed is then no longer automatically wired because the standard interface X100
intended for the infeed is already occupied (e.g. with the Mot
or Module).
In this case, the device configuration must be changed manually. You can wire the infeed
manually to a free interface (see Section "
Editing a DRIVE-CLiQ connection (Page 100)").
You can also change the wiring of the drive object that is currently linked to X100 of the
drive, to a different interface. X100 would then be free again and when the infeed is inserted,
it is automatically linke
d to X100.
Note
Handling components in the device view is subsequently explained using an infeed as
example. The procedure is identical for all other components.
