Diagnostics
5.3 Diagnostics via Startdrive
Commissioning with Startdrive
Commissioning Manual, 11/2017, 6SL3097-4AA10-0BP1
345
Transferring the trace configuration to the device
Requirement
● A valid trace configuration is provided in the "Traces" system folder.
● The maximum number of traces has still not been reached.
Proceed as follows to transfer a trace configuration to the drive:
1. Open a valid trace configuration in the working area.
2. Click on icon
.
The "Go online" dialog is displayed if an online connection to the drive has not been
active up until now.
Here, make the settings for the online connection (also see Chapter "Establishing an
online connection to the drive unit (Page 137)") and click on "Connect".
The trace configuration is transferred to the drive.
Activating/deactivating the trace recording
Requirement
● An online connection has been established to the drive.
● A trace is saved in the drive.
● The trace configuration in the drive is displayed in the working area (see Chapter
"Creating or calling a trace (Page 339)").
● The icon
for monitoring the displayed trace is enabled.
