Sensor dimension Unit Range
DN 80 Mass flow kg/s 0 to +251
Volume flow m
3
/s 0 to +0.249
DN 100 Mass flow kg/s
Volume flow m
3
/s
DN 150 Mass flow kg/s
Volume flow m
3
/s
A.2.5 Zero point adjustment: Sensor dimension dependent default settings (Process
values)
Zero point adjustment
Sensor dimension Default value
kg/s
Default value
kg/h
Standard deviation limit
DN 15 0.0008 2.88
DN 25 0.0027 9.72
DN 50 0.009 32.4
DN 80 0.04 144
DN 100 0.0832 299.52
DN 150 0.1376 495.36
Offset limit
DN 15 0.012333333 44.4
DN 25 0.056166667 202.2
DN 50 0.140444444 505.6
DN 80 0.368611111 1327
DN 100 0.783 2820
DN 150 1.269 4570
Sensor dimension Default value
m³/s
Hysteresis
DN 15 0
DN 25 0
DN 50 0
DN 80 0
DN 100 0
DN 150 0
Technical reference
A.2 Sensor dimension dependent default settings
SITRANS FC330
Operating Instructions, 01/2019, A5E44030648-AB 233
