REPORTS & LOGS
5-7
SIG-QG-20-02 JANUARY 2021
Version : A.2
5.4 OCCN LOG (GCP4000/5000)
The display module and CPU III provide a new log to aid in tracking down issues where the OCCNs do
not match the current plan. This is primarily intended for use once the system is in service and in a
maintenance mode. The new log easily allows parameters changed which have altered the OCCN to be
seen.
NOTE
The OCCN Log is only available from the Display module when the Display Module
has a version after 1.5.7r and is used with CPU II+ versions later than
ncg05_30.mef or CPU III versions later than 9VC72-V3H01_00.mef.
NOTE
The OCCN Log is only available from the CP Web UI when the CPU III has CP
version later than 1.1.61r.
The log is cleared whenever the configuration is set to default, a new MCF loaded, or a PAC file loaded.
The log is stored in the CIC on the chassis and so it will be retained even if CPUs or display modules are
swapped out and provides a long term history of OCCN parameter changes.
The option is available on the Local UI on the Reports and Logs page.
Figure 5-11 shows the OCCN log from the GCP 4000, the OCCN value is recorded when the user
selects to recalculate the OCCN from the check number screen.
