Operating Manual - English Triax QUATTRO
- 16 - Copyright Silca 2011
1
3.4 WORK STATION DESCRIPTION
Only one operator is required to work the key-cutting machine and the following controls are available:
1. Master switch on the back of the machine.
2. Key-positioning clamp.
3. Control keypad.
4. Display.
5. Emergency button.
3.5 GRAPHICS
Adhesive labels on the Plexiglas safety shield:
1. Do not use compressed air.
Divieto di usare aria compressa
per operazioni di pulizia
2. ATTENTION DANGEROUS MOBILE PARTS
Available on the accessories provided. It is obligatory to apply it to the left-hand side of the machine
safety shield (see Fig. 10).
ATTENZIONE
PARTI MOBILI
PERICOLOSE
Fig. 10
It is forbidden to remove the labels.
ATTENTION
DANGEROUS
MOBILE PARTS
DO NOT USE
COMPRESSED AIR
