Operating Manual - English Triax QUATTRO
Copyright Silca 2011 - 41 -
5.8 ENGRAVING
The Triax QUATTRO key-cutting machine can use the R12 clamp and W146 cutter to engrave texts on various
items, such as the head or stem of keys (flat, laser, dimple) or medals, plates, etc.
The items can be in several types of material: aluminium, brass, steel, etc.
Duration of the cutter depends on the hardness of the material to be engraved and the size of the text (number
of lines) (see indicative table).
* the keys and medals must be metal.
Engraving on other materials (wood, paper, ceramics, etc.) is not allowed.
* the maximum dimensions of the part to be engraved are: 38x40 mm (see fig. 21)
5.8.1
ENGRAVING TEMPLATE PARAMETERS
The key-cutting machine can be used without a PC, but with certain limitations.
To make use of all the potential available it is advisable to use the special function included in the Triax
Engraving Program (see machine accessories) and Silca Key Programs.
Engraving templates are made up of the parameters defining an engraving job:
No. of lines Max 8
Text alignment LH - Centred - RH
Character height 1.5 mm to 10 mm
(0.059” to 0.394”)
Font One only
Special functions 2 self-increasing functions (counters)
Use of TOKENS with SKP and SSI T0 – T7
Possibility to engrave 2 sides of the key using the same template (front-back) Yes
Key thickness 1 to 4 mm
(0.039” to 0.157”)
Engraving depth 5 to 30 hundredths of mm
(0.002” to 0.012”)
Clamp From those available (R12,…)
Cutter From those available (146W, …)
