Simrad GO7 User Manual

- When the automatic routing is completed the route appears
in preview mode, and the legs are color coded to indicate safe
or unsafe areas. Navionics uses red (unsafe) and green (safe),
while C-MAP uses red (unsafe), yellow (dangerous) and green
(safe).
4. Move any routepoints if required when the route is in preview
mode.
5. Select Keep to accept the routepoints positions.
6. Eventually repeat step 2 (Selection) and step 3 if you want the
system to automatically position routepoints for other parts of
the route.
7. Select Save to complete the automatic routing and save the
route.
Autorouting and Easy Routing examples
• Entire route option used when first and last route points are
selected.
First and last routepoint Result after automatic routing
• Selection option used for autorouting part of a route.
Two routepoints selected Result after automatic routing
46
Waypoints | GO7 Operator Manual

Simrad GO7 Specifications

General

Resolution	800 x 480 pixels
Touchscreen	Yes
Networking	NMEA 2000
Bluetooth	Yes
Chartplotter	Yes
Display Size	7 inch
GPS Type	Internal
Wireless Connectivity	Wi-Fi
Chart Compatibility	C-MAP, Navionics
Display Type	TFT LCD
SD Card Slots	1
Sonar Compatibility	CHIRP
Radar Compatibility	Yes
Operating Temperature	-15°C to 55°C
Sonar	Broadband, CHIRP, DownScan, SideScan (with compatible transducer)
