4.7.1 Switching points with BIBO reservoir
design
Fig.
16
Switching points
Table
14
Switching points
Reservoir size
D1
mm
D2
mm
D3
mm
Liters
[gal.]
<Content>
2
[0.53]
50
165
160
4
[1.06]
65
150
140
D1 = full signal, D2 = low-level signal,
D3 = pre-empty signal
