4.8 Reservoir designs
The possible reservoir designs for the pumps described in these instructions can be found below (see also the type
identification code). To improve the clarity of the illustrations, only the smallest possible reservoir size is shown in each
case. The differences between the reservoir designs may not be visible in the illustrations, as the differences lie in the
internal structure (e.g. with and without low-level signal).
Table
Figure
Reservoir size in liters and [gal.]
X = available reservoir sizes.
*
With these reservoir sizes, the installation of a pressure limiting valve in the pump element requires the adapter
-14105-5 (see also spare parts).
