SKF P203 - Electrical Data; Nominal Delivery Rates

20
4.2 Electrical data
Table
8
Electrical data
Parameter
Values
12 VDC pump
24 VDC pump
Enclosure rating
1)
IP69K
IP69K
Protection classes
•
Rectangular connector
•
Bayonet connector
•
Screwed gland with cable and Deutsch
male connector
SELV / PELV / FELV
SELV / PELV
SELV / PELV
SELV / PELV / FELV
SELV / PELV
SELV / PELV
Rated voltage ±10 %
12 VDC
24 VDC
Current input up to
6 A
3 A
Recommended back-up fuse
6.0 A (slow)
3.0 A (slow)
Output signal
Non-isolated
Non-isolated
Switching voltage, max.
30 VDC
30 VDC
Switched current, max.
700 mA
700 mA
1)
The specified enclosure rating of the pump requires the use of IP69K-compliant connection sockets and corresponding
cables. If connection sockets and cables with a lower protection rating are used, the lowest of those ratings will apply as
the enclosure rating. For the enclosure ratings achievable when using the connection sockets and cable supplied by us,
see the “Spare parts” chapter.
4.3 Nominal delivery rates
NOTE
The specified nominal delivery rates per stroke apply to NLGI grade 2 lubrication greases in the case of pump elements
5, 6, 7, and R and to NLGI grade
0 lubrication greases in the case of pump element L, in all cases at an ambient
temperature of +20
°C [68 °F] and a back pressure of 100 bar [1450 psi] at the pump element.
Differences in operating conditions or a different pump configuration will lead to changes in the motor speed and thus to
a change in the delivery rate per unit of time. If the change in the motor speed necessitates an adjustment to the delivery
rate per unit of time, then this will be reasonably accomplished by adjusting the lubrication and pause time setting of the
pump.
Table
9
Nominal delivery rate per stroke
Pump element
L
1)
5
6
7
R
B
C
2)
Nominal delivery rate
per stroke
0.03 ccm
0.10 ccm
0.16 ccm
0.22 ccm
0.04 - 0.18 ccm
0.10 ccm
0.24 ccm
1)
The pump element L must not be used on pumps with a follower plate. With pump element L, lubricants below NLGI
Grade 2 as specified in these instructions can be pumped without restriction. For lubricants of NLGI Grade 2, the
suitability of the pump element L at temperatures of -5 °C or lower must be checked on a case-by-case basis.
2)
The pump element “C” is designed only for pumping chisel paste. When using chisel paste, observe the relevant
information in the “Lubricants” section.
