37
Table
24
Possible connection types:
Housing position
Left
Right
Bottom
Top
Bottom
Top
I
II
I
II
I
II
I
II
Description
Coding and connection on the pump housing:
0
-
0
-
0
-
0
-
0
No connection
A
-
-
-
-
A
Rectangular connector - control circuit board/supply line,
V10
-V13 (pins 2 and 3 occupied)
C
-
-
-
-
C
Rectangular connector - control circuit board/supply line,
V10-V13 (pins 1 and 3 occupied)
E
-
-
-
-
E
Rectangular connector - control circuit board/supply line,
V20
-V23
-
L
-
-
-
L
M12 connector, 5-pin, A-coded
-
5
-
-
-
5
Bayonet connector, 4/3-pin
-
R
-
-
-
R
Bayonet connector, 7/6-pin
-
8
-
-
-
8
Conduit union with cable + Deutsch plug
-
-
F
-
-
F
Rectangular connector - control circuit board/signals
Coding and accessories for connection:
-
0
-
0
-
0
-
0
0
Without connection socket, without cable
-
1
-
-
-
1
With connection socket, without cable (black)
-
A
-
-
-
A
With connection socket and 10 m cable
-
C
-
-
-
C
With connection socket and 10 m ADR cable
-
L
-
-
-
L
With connection socket and 6 m cable (USA pumps)
-
-
E
-
-
E
With connection socket and 10 m cable, 4/3-core, LLC
-
-
G
-
-
G
With connection socket and 10 m cable, 7/6-core, LLC+LDT
-
-
M
-
-
M
With bayonet socket and 6 m cable, 7/3-core (USA pumps)
2
2
With connection socket, without cable, gray
B
B
With connection socket and 10 m cable
D
D
With connection socket and 10 m ADR cable
