10
Installation
Service Manual
SKOPE TME/SKT ActiveCore
Procedure 7: To lower the top shelf light and ticket strip
1. Isolate the fridge from the power supply (see “Replacement Procedures” on page 23).
2. Unclip the shelf light assembly from the front of
the shelf.
3. Take care of the wires while handling the shelf
light.
4. Slide the ticket strip off the clips.
5. Detach the two standard clips from the light, and
replace with two grey clips.
6. Slide the ticket strip onto the grey clips.
7. Fit the shelf light assembly onto the front of the shelf.
8. Connect cabinet to the power supply and check for correct operation.
Ticket strip
Standard clip
Grey clip
Light
