SKOPE TME/SKT ActiveCore
Replacement Procedures
Service Manual
4 Replacement Procedures
Lighting
Depending on the model, the cabinet may be fitted with an LED tube sign light, LED tube
interior side light/s, LED modular interior side lights, or LED modular shelf lights.
See the table below for light tube specifications. Before replacing a light, determine the light
specification and part number, and replace with the same light type. Fluorescent tubes cannot
be used in place of LED tubes.
Refer to the table below for replacement light specifications.
Note: LED tube lights may be fitted with rotating end caps at each end of the tube. Ensure both
end caps are positioned at the ‘0’ setting and that the light faces the correct direction.
LED Tube Side
Lighting
LED tube side lit cabinets are lit by one or two T8 LED tube side lights, which can be replaced
without moving shelves or product.
IMPORTANT
Replace the light with the same type (LED tube or modular
light). DO NOT use fluorescent tubes.
Table 7: Light specifications
Model Interior light Sign light
Description Part No. Description Part No.
TME650-A
LED tube side light ELL10180
n.a. n.a.
TME650-AC LED tube sign light ELL10741
TME1000-A n.a. n.a.
TME1000-AC LED tube sign light ELL11288
TME1500-A
LED tube side light and modular
pillar light
ELL10180
ELL11049
n.a. n.a.
TME1500-AC LED tube sign light ELL10743
SKT650-A
LED modular side light ELL11049
n.a. n.a.
SKT650-AC LED tube sign light ELL10741
SKT650-ACX LED modular side and shelf lights
ELL11049
ELL11048
LED tube sign light ELL10741
SKT1000-A
LED modular side light ELL11049
n.a. n.a.
SKT1000-AC LED tube sign light ELL11288
SKT1000-ACX LED modular side and shelf lights
ELL11049
ELL11388
LED tube sign light ELL11288
SKT1500-A
LED modular side/pillar light ELL11049
n.a. n.a.
SKT1500-AC LED tube sign light ELL10743
SKT1500-ACX LED modular shelf light ELL11388 LED tube sign light ELL10743
