SKOPE TME/SKT ActiveCore
Replacement Procedures
Service Manual
Refrigeration Unit
Refrigeration
Unit Assembly
The SKOPE ActiveCore refrigeration unit is an electronically controlled removable unit.For
servicing or transportation, the refrigeration unit unplugs and lifts off the TME cabinet. Some
minor servicing can be performed without removing the refrigeration unit.
The model and serial number are both printed on the unit rating/serial number label attached
to the top of the unit (see image below). Before ordering spare parts take note of the model
and serial numbers.
Specifications for the model are in the following table. Verify model and basic requirements
before servicing.
Table 9: Unit specifications
Unit model
UTHCCI-0002
(part number: HB0070823484)
UTHCCI-0004
(part number: HB0070826577)
Compressor Embraco FFI12HBK Kirby Kulthorn CA9440Y
Compressor capacity 836 Watts 1000 Watts
Refrigerant R134a R134a
Charge 380 g 475 g
