SKOPE TME/SKT ActiveCore
Spare Parts
Service Manual
Notes:
Check the part colour before ordering. If the colour differs from the list above, state the specific colour when ordering.
* If key lock/s are fitted, please contact SKOPE for part number.
** When ordered as a spare part, the refrigeration unit does not include evaporator box lid, top metal strap brackets,
or hold down brackets. If required, these items must be ordered in addition to the refrigeration unit (items 17, 18 and
19).
Table 13: Parts – Cabinet assembly: TME650 series, SKT650 series
No. Description
Part No.
Unpainted/standard Colour: White Colour: Black
1 Shelf clip – HB0070205867 PLM10903BK
2 Shelf support strip HB0070110331 – –
3 Wire shelf – HB0070110864 –
4
Door assembly – standard* – HB0070824789 GLD11403R-BK
Door assembly – tropical* – GLD11404R-WH GLD11404R-BK
Door assembly – solid* MT65SZ/D40 MT65SZ/D40-32 MT65SZ/D40-49
5 Door lock bracket – cabinet piece – HB0070110584A HB0070110584A
6 Top hinge – right hand – HB0070110582B SM12BV/388R-49
7 Bottom hinge – right hand – HB0070110851 SM10BV/393R-49
8 Tension bracket – – HB0070110580
9 Vertical lock nut – – HB0070110581
10
Rear castor – TME650 Series HB0070105066 – –
Rear castor – SKT650 Series SXX4339 – –
11
Front castor lockable – TME650 Series HB0070105065 – –
Front castor lockable – SKT650 Series SXX4539 – –
12 Controller clip – HB0070206333 HB0070206333A
13 Sign side – SM65BV/182-32 SM65BV/182-49
14 Sign back strip – HB0070110813 SM65BV/C53-49
15
Sign replacement panel – TME650-A – HB0070825987 –
Sign replacement panel – SKT650-A* – MT65GV/S22-32 MT65GV/S22-49
Lit sign assembly (excluding LED tube) – TME650-AC – HB0070825410 –
Lit sign assembly (excluding LED tube) – SKT650-AC and
SKT650-ACX*
– MT65BV/T61-32 MT65BV/T61-49
16 Refrigeration unit assembly** HB0070823484 – –
17 Evaporator box lid HB0070511356 – –
18 Top metal strap bracket HB0070110816 – –
19 Hold down bracket HB0070110815 – –
20 Optional condenser filter FIL11321 – –
21 Door switch HB0074091496-1 – –
–
Door switch flex (not shown) – TME650 Series HB0070400586A – –
Door switch flex (not shown) – SKT650 Series MT65BV/X04 – –
–
Side light assembly (not shown) – TME650 Series – HB0070825407 –
Side light assembly (not shown) – SKT650 Series – MT65BY/L10R-32 MT65BY/L10R-49
– Shelf light assembly (not shown) – SKT650-ACX See page 60 – –
– Mains flex (not shown) HB0070400636 – –
– Key lock (not shown) SXX11581 – –
– Hinge reversal kit – left hand (not shown) – SM65BV/D100-32 SM65BV/D100-49
