SKOPE TME/SKT ActiveCore
Spare Parts
Service Manual
Notes:
Check the part colour before ordering. If the colour differs from the list above, state the specific colour when ordering.
* If key lock/s are fitted, contact SKOPE for the part number.
** When ordered as a spare part, the refrigeration unit does not include evaporator box lid, top metal strap brackets,
or hold down brackets. If required, these items must be ordered in addition to the refrigeration unit (items 17, 18 and
19).
5
Door assembly left hand – standard* – HB0070824787 GLD11372L-BK
Door assembly left hand – tropical* – GLD11406L-WH GLD11406L-BK
Door assembly left hand – solid* MT10SZ/D41 MT10SZ/D41-32 MT10SZ/D41-49
6 Door lock bracket – cabinet piece – HB0070110584A HB0070110584B
7 Top hinge – right hand – HB0070110582B SM12BV/388R-49
8 Top hinge – left hand – HB0070110583B SM12BV/388L-49
9 Bottom hinge – right hand – HB0070110851 SM10BV/393R-49
10 Bottom hinge – left hand – HB0070110850 SM10BV/393L-49
11 Tension bracket – – HB0070110580
12 Vertical lock nut – – HB0070110581
13
Rear castor – TME1000 Series HB0070105066 – –
Rear castor – SKT1000 Series SXX4339 – –
14
Front castor lockable – TME1000 Series HB0070105065 – –
Front castor lockable – SKT1000 Series SXX4539 – –
15
Centre pillar assembly – TME1000 Series – HB0070825318 –
Centre pillar assembly – SKT1000 Series – MT15BY/L40N-32 MT15BY/L40N-49
16 Controller clip – HB0070206333 HB0070206333A
17 Sign side – SM65BV/182-32 SM65BV/182-19
18 Sign back strip – HB0070110812 SM10BV/C53-49
19
Sign replacement panel – TME1000 Series – HB0070825986 –
Sign replacement panel – SKT1000 Series – MT10GV/S22-32 MT10GV/S22-49
Lit sign assembly (excluding LED tube) – TME1000 Series – HB0070825408 –
Lit sign assembly (excluding LED tube) – SKT1000 Series* – MT10BV/T61-32 MT10BV/T61-49
20* Refrigeration unit assembly* HB0070823484 – –
21 Evaporator box lid HB0070511356 – –
22 Top metal strap bracket HB0070110816 – –
23 Hold down bracket HB0070110815 – –
24 Optional condenser filter FIL11321 – –
25 Door switch HB0074091496-1 – –
–
Door switch flex (not shown) – TME1000 Series HB0070400584 – –
Door switch flex (not shown) – SKT1000 Series MT10BV/X04 – –
–
Side light assembly (not shown) – TME1000 Series – HB0070825407 –
Side light assembly left hand (not shown) – SKT1000 Series – MT65BY/L10L-32 MT65BY/L10L-49
–
Side light assembly, right hand (not shown) – SKT1000
Series
– MT65BY/L10R-32 MT65BY/L10R-49
– Shelf light assembly (not shown) – SKT1000-ACX See page 60 – –
– Cabinet power flex (not shown) HB0070400579 – –
– Key lock (not shown) SXX11581 – –
– Mains flex (not shown) HB0070400636 – –
Table 14: Parts – Cabinet assembly: TME1000 series, SKT1000 series (continued)
No. Description
Part No.
Unpainted/standard Colour: White Colour: Black
