SKOPE TME/SKT ActiveCore
Spare Parts
Service Manual
Note:
Check the part colour before ordering. If the colour differs from the list above, state the specific colour when ordering.
Table 16: Parts – Glass door assembly TME650 series, SKT650 series
No. Description
SKOPE Part No.
Unpainted/standard Colour: White Colour: Black
Door assembly – right hand – HB0070824789 GLD11403RH-BK
1
Door handle –
HAN11195/0844-AS (silver, for white
door)
HAN11195/0844-49
2
Magnetic gasket GKT0432SK – –
3
Bush PLM5075 – –
4
Torsion bar REF5014 – –
5
Capstan SM12BV/396 – –
6
Door switch magnet HB0074091496 – –
7
Door lock bracket – door piece HB0070109269 – –
8
Bush washer PLM11298 – –
9
Split pin FAS5076 – –
Table 17: Parts – Glass door assembly TME1000/1500 series, SKT1000/1500 series
No. Description
SKOPE Part No.
Unpainted/standard Colour: White Colour: Black
Door assembly – right hand – HB0070824788 GLD11372R-BK
Door assembly – left hand – HB0070824787 GLD11372L-BK
Door assembly – middle (TME/
SKT1500 series)
– HB0070824788 GLD11372R-BK
1
Door handle –
HAN11195/0844-AS (silver, for white
door)
HAN11195/0844-49
2
Magnetic gasket GKT0572SK – –
3
Bush PLM5075 – –
4
Torsion bar REF5014 – –
5
Capstan SM12BV/396 – –
6
Door switch magnet HB0074091496 – –
7
Door lock bracket – door piece HB0070109269 – –
8
Bush washer PLM11298 – –
9
Split pin FAS5076 – –
–
Door stop (middle door) (not shown) MT15BV/400R-32 – –
