Skope TME ActiveCore - Page 59

59
SKOPE TME/SKT ActiveCore
Spare Parts
Service Manual
Note:
Check the part colour before ordering. If the colour differs from the list above, state the specific colour when ordering.
Table 18: Parts – Solid door assembly SKT650S-A
No. Description
SKOPE Part No.
Unpainted/standard Colour: White Colour: Black
Door assembly – right hand MT65SZ/D40 MT65SZ/D40-32 MT65SZ/D40-49
1
Magnetic gasket GKT0432SK – –
2
Bush PLM5075 – –
3
Torsion bar REF5014 – –
4
Capstan SM12BV/396 – –
5
Door switch magnet HB0074091496 – –
6
Door lock bracket – door piece – HB0070109269P HB0070109269Q
7
Bush washer PLM11298 – –
8
Split pin FAS5076 – –
Table 19: Parts – Solid door assembly SKT1000S-A
No. Description
SKOPE Part No.
Unpainted/standard Colour: White Colour: Black
Door assembly – right hand MT10SZ/D40 MT10SZ/D40-32 MT10SZ/D40-49
Door assembly – left hand MT10SZ/D41 MT10SZ/D41-32 MT10SZ/D41-49
1
Magnetic gasket GKT0572SK – –
2
Bush PLM5075 – –
3
Torsion bar REF5014 – –
4
Capstan SM12BV/396 – –
5
Door switch magnet HB0074091496 – –
6
Door lock bracket – door piece – HB0070109269P HB0070109269Q
7
Bush washer PLM11298 – –
8
Split pin FAS5076 – –
Table 20: Parts – Solid door assembly SKT1500S-A
No. Description
SKOPE Part No.
Unpainted/standard Colour: White Colour: Black
Door assembly – right hand MT10SZ/D40 MT10SZ/D40-32 MT10SZ/D40-49
Door assembly – left hand MT10SZ/D41 MT10SZ/D41-32 MT10SZ/D41-49
Door assembly – middle MT15SZ/D42 MT15SZ/D42-32 MT15SZ/D42-49
1
Magnetic gasket GKT0572SK – –
2
Bush PLM5075 – –
3
Torsion bar REF5014 – –
4
Capstan SM12BV396 – –
5
Door switch magnet HB0074091496 – –
6
Door lock bracket – door piece – HB0070109269P HB0070109269Q
7
Bush washer PLM11298 – –
8
Split pin FAS5076 – –
–
Door stop (not shown) MT15BV/400L-32 – –
