SKOPE TME/SKT ActiveCore
Spare Parts
Service Manual
* Note:
When ordered as a spare part, the refrigeration unit does not include evaporator box lid and top metal strap bracket.
If required, these items must be ordered in addition to the refrigeration unit (items 2 and 21).
Table 31: Parts – Unit assembly UTHCCI-0004 TME1500 series, SKT1500 series
No. Description SKOPE Part No.
Unit assembly* HB0070826577
1
Evaporator box HB0070510928
2
Evaporator box lid HB0070511356
3
Evaporator coil HB0070702232A
4
Evaporator fan motor HB0074000581
5
Evaporator fan blade HB0074000313A
6
Evaporator fan shroud HB0070206123
7
Condenser coil HB0070702233A
8
Condenser fan motor HB0074000513
9
Condenser fan blade FAN5043
10
Condenser fan shroud HB0070206124
11
Compressor – Kulthorn Kirby CA9440Y HB0074000266
Compressor electrics kit HB0074000266
Start relay HB0074000266-1
Start capacitor HB0074000266-2
Run capacitor HB0074000266-3
Overload HB0074000266-4
12
Drier HB0070700780
13
Suction line assembly HB0070702236A
14
Accumulator (142 mm) V8100/496
15
High pressure switch HB0074000537
16
Condensate pipe support HB0070110674
17
Unit gasket seal 1571 mm PLE11052-1571
18
Unit gasket seal 2308 mm PLE11052-2306
19
Unit plastic top cover HB0070206133
20
Unit plastic bottom HB0070206212
21
Unit electrics box assembly HB0070825230
22
Hold down bracket HB0070110815
23
Top metal strap bracket HB0070110816
