Flashing Bootloader
Tools required
After manufactured boards come without bootloader pre-installed. You can easily flash them yourself. The tools which will be needed:
ST-Link v2 ARM JTAG Debugger
ARM JTAG Mini connector 1.25 mm pitch
Connections
ST Link debugger looks as following:
You will need to connect ST-Link pins to SmartAP Pins.
The reference for ST Link pins:
