SMC Networks EX600-SEN3 User Manual

-100-
No.EX※※-OMX1011
Configuration format (EX600-DM#E/F)
Byte
Bit
EX600-DM#E/F (10 byte)
Parameter
Setting value
0
0..3
Unit No.
0..8
4..7
Parameter type
1
1
0..7
Unit ID
EX600-DM#E: 1C (Hex)
EX600-DM#F: 1E (Hex)
Unit parameter
2
0
Monitor short circuit (power)
0: disable, 1: enable
1
Monitor short circuit (out)
0: disable, 1: enable
2
Inrush current filter
0: disable, 1: enable
3
Restart after short circuit (Output)
0: manual, 1: auto
4..5
Input filtering time
0: 0.1 ms, 1: 1 ms, 2: 10 ms, 3: 20 ms
6..7
Input extension time
0: 1 ms, 1: 15 ms, 2: 100 ms, 3: 200 ms
Channel parameter – Channel 0 to 7
3
0
(Ch0 input) Monitor counter
0: disable, 1: enable
~
~
~
7
(Ch7 input) Monitor counter
0: disable, 1: enable
4
0
(Ch0 output) Monitor counter
0: disable, 1: enable
~
~
~
7
(Ch7 output) Monitor counter
0: disable, 1: enable
5
0
(Ch0 output) Monitor open circuit
0: disable, 1: enable
~
~
~
7
(Ch7 output) Monitor open circuit
0: disable, 1: enable
6
0
(Ch0 output)
Output setting during communication Fault
0: hold
1: depend on fault value
~
~
~
7
(Ch7 output)
Output setting during communication Fault
0: hold
1: depend on fault value
7
0
(Ch0 output) Fault value
0: clear, 1: ON
~
~
~
7
(Ch7 output) Fault value
0: clear, 1: ON
8
0
(Ch0 output)
Output setting during communication idling
0: hold
1: depend on Idle value
~
~
~
7
(Ch7 output)
Output setting during communication idling
0: hold
1: depend on Idle value
9
0
(Ch0 output) Idle value
0: clear, 1: ON
~
~
~
7
(Ch7 output) Idle value
0: clear, 1: ON
