SMC Networks EX600-SEN3 User Manual

-112-
No.EX※※-OMX1011
2. QuickConnect
TM
function setting
Change the TCP/IP Object to the values shown below.
Make sure the value is set to "0" when the QuickConnect
TM
function is not used.
Class
Instance
Attribute
Value
QuickConnect
TM
setting
0xF5
0x01
0X0C
0: disabled (default setting)
1: enabled
○
Note) Upon configuration of QuickConnect
TM
functions, the polarities of the communication ports
reverse, as shown in the table below. Please be aware when selecting communication
cables and the polarity of the communication port of the connected device.
Quick Connect
TM
setting
BUS IN Port
BUS OUT Port
Disabled
AUTO MDI/MDI-X
AUTO MDI/MDI-X
Enabled
MDI
MDI-X
