-101-
No.EX※※-OMX1011
Configuration format (EX600-AXA)
Byte
Bit
EX600-AXA (14 byte)
Parameter
Setting value
0
0..3
Unit No.
0..8
4..7
Parameter type
1
1
0..7
Unit ID
20 (Hex)
Unit parameter
2
0
Monitor short circuit
0: disable, 1: enable
1..3
Reserved
-
4
(Ch0&1 in) Monitor over range
0: disable, 1: enable
5
(Ch0&1 in) Monitor under range
0: disable, 1: enable
6..7
Data format
0: offset binary, 1: signed magnitude,
2: 2’s complement
Channel parameter – Channel 0 to 1
3
0..2
(Ch0 in) Analogue input range
0: -10..+10 V, 1: -5..+5 V,
2: -20..+20 mA
3: 0..10 V, 4: 0..5 V, 5: 1..5 V,
6: 0..20 mA, 7: 4..20 mA
3
Reserved
-
4..6
(Ch1 in) Analogue input range
0: -10..+10 V, 1: -5..+5 V,
2: -20..+20 mA
3: 0..10 V, 4: 0..5 V, 5: 1..5 V,
6: 0..20 mA, 7: 4..20 mA
7
Reserved
-
4
0..1
(Ch0 in) Analogue average filter
0: None, 1: 2 value average,
2: 4 value average, 3: 8 value average
2..3
Reserved
-
4..5
(Ch1 in) Analogue average filter
0: None, 1: 2 value average,
2: 4 value average, 3: 8 value average
6..7
Reserved
-
5
0
(Ch0 in) Monitor upper limit
0: disable, 1: enable
1
(Ch1 in) Monitor upper limit
0: disable, 1: enable
2..3
Reserved
-
4
(Ch0 in) Monitor lower limit
0: disable, 1: enable
5
(Ch1 in) Monitor lower limit
0: disable, 1: enable
6..7
Reserved
-
6..7
0..7
(Ch0 in) Upper limit value
0 to 65535 (Low byte first)
8..9
0..7
(Ch0 in) Lower limit value
0 to 65535 (Low byte first)
10..11
0..7
(Ch1 in) Upper limit value
0 to 65535 (Low byte first)
12..13
0..7
(Ch1 in) Lower limit value
0 to 65535 (Low byte first)
