-94-
No.EX※※-OMX1011
Configuration assembly
■Parameter setting of EX600 with configuration assembly
The Configuration assembly function enables PCL to send parameters to the EX600 under the EtherNet/IP
communication connection.
: This function may not be available due to the PLC type.
: The settable data size in the configuration assembly is 456 bytes maximum.
•Unit ID list
Each unit has an individual unit ID. Describe the set value by specifying "the total number of Unit No. and
parameter" and "Unit ID".
Unit IDs are described below.
Unit
Unit part number
Unit ID
Configuration data size [byte]
SI unit
EX600-SEN3-X80 (32 outputs)
9Bh
27
Digital input unit
EX600-DX#B (8 inputs)
01h
4
EX600-DX#C (8 inputs)
03h
4
EX600-DX#D (16 inputs)
05h
5
EX600-DX#E (16 inputs)
14h
5
EX600-DX#F (16 inputs)
16h
5
EX600-DX#C1 (8 inputs)
0Dh
5
Digital output unit
EX600-DY#B (8 outputs)
08h
9
EX600-DY#E (16 outputs)
18h
15
EX600-DY#F (16 outputs)
1Ah
15
Digital I/O unit
EX600-DM#E (8 inputs / 8 outputs)
1Ch
10
EX600-DM#F (8 inputs / 8 outputs)
1Eh
10
Analog input unit
EX600-AXA (2 inputs)
20h
14
Analog output unit
EX600-AYA (2 outputs)
22h
21
Analog I/O unit
EX600-AMB (2 inputs / 2 outputs)
23h
32
IO-Link unit
EX600-LAB1 (Class A)
3Bh
46
EX600-LBB1 (Class B)
3Ch
46
