■IO-Link SMI service
Reading and writing of the IO-Link master and device parameter using EtherNet/IP
TM
Explicite Message.
The service code of the Explicit Message varies in reading and writing.
•Reading: 32h
•Writing: 33h
The following 5 types of data can be read or written in the SMI service.
No
Description
Data type
Read
Write
1
SMI_MasterIdentification
IO-Link master information

-
2
SMI_PortConfiguration
IO-Link master port parameter setting


3
SMI_PortStatus
Acquires IO-Link master port status

-
4
SMI_DeviceRead
Receives ISDU from IO-Link device

-
5
SMI_DeviceWrite
Sends ISDU to IO-Link device
-

1. SMI_MasterIdentification (acquires IO-Link master information: Read)
[Request]
Data
Value
Notes
Service code
0x32
Class
0x90
Instance
0x01 to 09
Unit No. +1
Attribute
0x64
Data[0]
0x00
Fixed value
Data[1]
0x01
Fixed value
[Response]
Data
Value
Notes
Ack[0] to [3]
0xB2000000
When reading is succeeded: 0xB2000000
Data[0] to [1]
Vendor ID
Vendor ID for the IO-Link master (SMC: 0x0083)
Data[2] to [5]
Master ID
IO-Link master ID
(EX600-LAB1: 0x0000003B, EX600-LBB1: 0x0000003C)
Data[6]
Master type
IO-Link master type (0x02)
Data[7] to [8]
Feature
Functions that IO-Link master supports (0x0400)
Data[9]
Max number of ports
Maximum IO-Link port quantity of the IO-Link master (0x04)
Data[10]
Port 1 type
Port type
0: Class A
1: Class A with PortPowerOffOn
2: Class B
Data[11]
Port 2 type
Data[12]
Port 3 type
Data[13]
Port 4 type
