SMC Networks EX600-SEN3 User Manual

-123-
No.EX※※-OMX1011
3. SMI_PortStatusList (Acquires IO-Link master port status: Read)
[Request]
Data
Value
Notes
Service code
0x32
Class
0x90
Instance
0x01 to 09
Unit No.+1
Attribute
0x65 to 68
Port No. 1 to 4
Data[0]
0x90
Fixed value
Data[1]
0x00
Fixed value
[Response]
Data
Value
Notes
Ack[0] to [3]
0xB2000000
When reading is successful: 0xB200000000
Data[0]
PortStatusInfo
0: NO_DEVICE, 1: DEACTIVATED, 2: PORT_DIAG
3: PREOPERATE, 4: OPERATE, 5: DI_C/Q, 6: DO_C/Q
Data[1].bit0
PortQualityInfo
input
0: Input process data valid
1: Input process data invalid
Data[1].bit1
PortQualityInfo
output
0: Output process data valid
1: Output process data invalid
Data[2]
RevisionID
IO-Link device revision ID
Data[3]
TransmissionRate
Communication speed
0: NOT_DETECTED, 1: COM1, 2: COM2, 3: COM3
Data[4]
MasterCycleTime
Port cycle time
Data[5]
InputDataLength
Process input data length
Data[6]
OutputDataLength
Process output data length
Data[7] to [8]
Vendor ID
Vendor ID of the IO-Link device connected
Data[9]
0x00
Reserved
Data[10] to [12]
Device ID
Device ID of the IO-Link device connected
Data[13]
NumberOfDiags
Event quantity
1
Data[14]
EventQualifier 1
EventQualifier1
2
Data[15] to [16]
EventCode
Event code of IO-Link master or device
3
Data[17]
EventQualifier 2
EventQualifier2
2
Data[18] to [19]
EventCode
Event code of IO-Link master or device
3
:
:
:
1: When the event quantity is "0", the data for Data[14] and later is not added.
When the event quantity is "1", the total amount of EventQualifier and event code 2 bytes (total bytes: 3) will be added. Data will be
added by 3 bytes according to the event quantity.
2: The specifications of EventQualifier# are described below.
Bit
7
6
5
4
3
2
1
0
Mode
Type
Source
Instance
0: Reserved
1: Event single shot
2: Event disappears
3: Event appears
0: Reserved
1: Notification
2: Warning
3: Error
0: Device
1: Master
0 : Unknown
1-3: Reserved
4 : Application
5-7: Reserved
3: Refer to IO-Link master unit (page 88) for details of the event code of the IO-Link master.
Refer to the Operation Manual of the IO-Link device for details of the event code of the IO-Link device.
