<Example 2>
Unit 0
Unit 1
Unit 2
Unit 3
Unit 4
Unit 5
End plate
AXA
Analogue
input
4 byte
Input
DY#B
Digital
output
1 byte
Output
DY#B
Digital
output
1 byte
Output
DX#B
Digital
input
1 byte
Input
DX#D
Digital
input
2 byte
Input
SEN3
SI unit
4 byte
Output
Valve
Input data: (Unit 0) Analogue input unit (EX600-AXA): 4 bytes occupied
(Unit 3) Digital input unit (EX600-DX#B): 1 byte occupied
(Unit 4) Digital input unit (EX600-DX#D): 2 bytes occupied
Output data: (Unit 1) Digital output unit (EX600-DY#B): 1 byte occupied
(Unit 2) Digital output unit (EX600-DY#B): 1 byte occupied
(Unit 5) SI unit (EX600-SEN3): 4 bytes occupied
•When Diagnostic mode 0 and byte order of analogue value (LSB-MSB) are selected.

1
Input data
Output data
Byte 0
AXA channel 0
(Unit 0)
Lo byte
Byte 0
DY#B (Unit 1)
Output 0 to 7
Byte 1
Hi byte
Byte 1
DY#B (Unit 2)
Output 0 to 7
Byte 2
AXA channel 1
(Unit 0)
Lo byte
Byte 2
SEN3 (Unit 5)
Output 0 to 7
Byte 3
Hi byte
Byte 3
Output 8 to 15
Byte 4
DX#B (Unit 3)
Input 0 to 7
Byte 4
Output 16 to 23
Byte 5
DX#D (Unit 4)
Input 0 to 7
Byte 5
Output 24 to 31
Byte 6
Input 8 to 15
Byte 6
Byte 7
Padding data
Byte 7
Total
8 bytes
Total
6 bytes
•When Diagnostic mode 0 and byte order of analogue value (MSB-LSB) are selected.

1
Input data
Output data
Byte 0
AXA channel 0
(Unit 0)
Hi byte
Byte 0
DY#B (Unit 1)
Output 0 to 7
Byte 1
Lo byte
Byte 1
DY#B (Unit 2)
Output 0 to 7
Byte 2
AXA channel 1
(Unit 0)
Hi byte
Byte 2
SEN3 (Unit 5)
Output 0 to 7
Byte 3
Lo byte
Byte 3
Output 8 to 15
Byte 4
DX#B (Unit 3)
Input 0 to 7
Byte 4
Output 16 to 23
Byte 5
DX#D (Unit 4)
Input 0 to 7
Byte 5
Output 24 to 31
Byte 6
Input 8 to 15
Byte 6
Byte 7
Padding data
Byte 7
Total
8 bytes
Total
6 bytes
1: Refer to "Parameter Setting" (page 58) for setting the byte order of analogue value.
