•SI unit parameters (1)
No.
Parameter
Definition
Item
Content
Default
setting
Parameter
setting range
1
Power supply
for control and
input voltage
monitor
Generated error
when control and
input power supply
voltage goes over
approx. 29 V or
under 18 V.
Enable
Generates an error.

Unit
Disable
Does not generate an
error.
2
Power supply
for output
voltage
monitor
Generated error
when output power
supply voltage
goes over approx.
29 V or under 19 V.
Enable
Generates an error.
Unit
Disable
Does not generate an
error.

3
Short Circuit
Detection
Generates error
when the short
circuit of the valve
is detected.
Enable
Generates an error.

Unit
Disable
Does not generate an
error.
4
Restart after
short circuit
Restore the setting
of short circuit
detection error
after the valve
short circuit is
cleared.
Auto
Error is automatically
cleared when the short
circuit is fixed.

Unit
Manual
Even when the short
circuit is fixed, error is not
cleared until the power is
supplied again.
5
Open Circuit
Detection
Generates error
when the
disconnection of
the valve is
detected.
Enable
Generates an error.
Channel
Disable
Does not generate an
error.

6
Output setting
during
communication
fault
1
Sets output when
communication
error is occurred.
Clear
Turn off the output

Channel
Hold
Hold the output
ForceON
Turn on the output
forcefully
7
Output setting
during
communication
idling
1 2
Output setting at
the time of
communication
idling
Clear
Turn off the output

Channel
Hold
Hold the output
ForceON
Turn on the output
forcefully
