-70-
No.EX※※-OMS0027
2. QuickConnect
TM
function setting
Change the TCP/IP Object to the values shown below.
Make sure the value is set to "0" when the QuickConnect
TM
function is not used.
Class Instance Attribute Value QuickConnect
TM
setting
0: disabled (default setting)
0xF5 0x01 0X0C
1: enabled
○
Note) Upon configuration of QuickConnect
TM
functions, the polarities of the communication ports
reverse, as shown in the table below. Please be aware when selecting communication
cables and the polarity of the communication port of the connected device.
Quick Connect
TM
setting BUS IN Port BUS OUT Port
Disabled AUTO MDI/MDI-X AUTO MDI/MDI-X
Enabled MDI MDI-X
To Next Page
