-124-
No.EX※※-OMX1011
4. SMI_DeviceRead (Acquires IO-Link device marameters: Read)
[Request]
Data
Value
Notes
Service code
0x32
Class
0x90
Instance
0x01 to 09
Unit No. +1
Attribute
0x65 to 68
Port No. 1 to 4
Data[0]
0x30
Fixed value
Data[1]
0x00
Fixed value
Data[2]
Index[0] (MSB)
Refer to the Operation Manual of the IO-Link Device
Data[3]
Index[1] (LSB)
Data[4]
Subindex
Refer to the Operation Manual of the IO-Link Device
[Response]
Data
Value
Notes
Ack[0] to [3]
0xB2000000
When reading is successful: 0xB2000000
Data[0] to [#]
On request data
Refer to the Operation Manual of the IO-Link Device
5. SMI_DeviceRead (IO-Link device parameter setting: Write)
[Request]
Data
Value
Notes
Service code
0x33
Class
0x90
Instance
0x01 to 09
Instance, Unit No. +1
Attribute
0x65..68
Port No. 1 to 4
Data[0]
0x30
Fixed value
Data[1]
0x00
Fixed value
Data[2]
Index[0] (MSB)
Refer to the Operation Manual of the IO-Link Device
Data[3]
Index[1] (LSB)
Data[4]
Subindex
Refer to the Operation Manual of the IO-Link Device
Data[5] to [#]
On request data
Refer to the Operation Manual of the IO-Link Device
[Response]
Data
Value
Notes
Ack[0] to [3]
0xB3000000
When writing is successful: 0xB3000000
