-27-
No.EX※※-OMX1011
End plate
Model Indication and How to Order
EX600-ED -
End plate at D side
Mounting method
Symbol
Description
Connector
Nil
No DIN rail bracket
Symbol
Connector
Key type
Function
2
With DIN rail bracket (VQC/SV/S0700 valve)
2
M12 (5 pin)
B code
IN
3
With DIN rail bracket (SY/JSY valve)
3
7/8 inch
(5 pin)
-
IN
4
M12
(4 pin/5 pin)
A code
IN/OUT
(PIN layout 1

)
5
M12
(4 pin/5 pin)
A code
IN/OUT
(PIN layout 2)
: Refer to Connector Pin No. (page 30) for details of the PIN
layout 1 and 2.
EX600-EU1-
End plate at U side
Mounting method
Symbol
Description
Nil
No DIN rail bracket
2
With DIN rail bracket (EX600-ED#-2)
3
With DIN rail bracket (EX600-ED#-3)
