Configuration format (EX600-DX#D/E/F)
Byte
Bit
EX600-DX#D/E/F (5 byte)
Parameter
Setting value
0
0..3
Unit No.
0..8
4..7
Parameter type
1
1
0..7
Unit ID
EX600-DX#D: 05 (Hex)
EX600-DX#E: 14 (Hex)
EX600-DX#F: 16 (Hex)
Unit parameter
2
0
Monitor short circuit (power)
0: disable, 1: enable
1
Reserved
0
2
Inrush current filter
0: disable, 1: enable
3
Reserved
0
4..5
Input filtering time
0: 0.1 ms, 1: 1 ms, 2: 10 ms, 3: 20 ms
6..7
Input extension time
0: 1 ms, 1: 15 ms, 2: 100 ms, 3: 200 ms
Channel parameter – Channel 0 to 7
3
0
(Ch0 input) Monitor counter
0: disable, 1: enable
~
~
~
7
(Ch7 input) Monitor counter
0: disable, 1: enable
Channel parameter – Channel 8 to 15
4
0
(Ch8 input) Monitor counter
0: disable, 1: enable
~
~
~
7
(Ch15 input) Monitor counter
0: disable, 1: enable
