SMC Networks EX600-SEN3 User Manual

-102-
No.EX※※-OMX1011
Configuration format (EX600-AYA)
Byte
Bit
EX600-AYA (21byte)
Parameter
Setting value
0
0..3
Unit No.
0..8
4..7
Parameter type
1
1
0..7
Unit ID
22 (Hex)
Unit parameter
2
0
Monitor short circuit
0: disable, 1: enable
1..5
Reserved
-
6..7
Analogue data format
0: offset binary, 1: signed magnitude,
2: 2’s complement, 3: Linear scaled,
Channel parameter – Channel 0 to 1
3
0..2
(Ch0 out) Analogue output range
3: 0..10 V, 4: 0..5 V, 5: 1..5 V,
6: 0..20 mA, 7: 4..20 mA
3
Reserved
-
4..6
(Ch1 out) Analogue output range
0 to 3: 0..10 V, 4: 0..5 V, 5: 1..5 V,
6: 0..20 mA, 7: 4..20 mA
7
Reserved
-
4
0
(Ch0 out)
Output setting for communication fault
0: hold, 1: depend on fault value
1
(Ch1 out)
Output setting for communication fault
0: hold, 1: depend on fault value
2
(Ch0 out)
Monitor upper limit value
0:disable, 1:enable
3
(Ch1 out)
Monitor upper limit value
0:disable, 1:enable
4
(Ch0 out)
Output setting for communication idling
0: hold, 1: depend on Idle
5
(Ch1 out)
Output setting for communication idling
0: hold, 1: depend on Idle
6
(Ch0 out)
Monitor lower limit value
0:disable, 1:enable
7
(Ch1 out)
Monitor lower limit value
0:disable, 1:enable
5..6
0..7
(Ch0 out) Upper limit value
0 to 65535 (Low byte first)
7..8
0..7
(Ch0 out) Lower limit value
0 to 65535 (Low byte first)
9..10
0..7
(Ch0 out) Fault value
0 to 65535 (Low byte first)
11..12
0..7
(Ch0 out) Idle value
0 to 65535 (Low byte first)
13..14
0..7
(Ch1 out) Upper limit value
0 to 65535 (Low byte first)
15..16
0..7
(Ch1 out) Lower limit value
0 to 65535 (Low byte first)
17..18
0..7
(Ch1 out) Fault value
0 to 65535 (Low byte first)
19..20
0..7
(Ch1 out) Idle value
0 to 65535 (Low byte first)
