I/O Map
Allocated input and output bytes of each unit type
Allocated input and output size is changable according to the diagnosis setting and connected EX600 unit
type. The allocated input and output bytes for each EX600 unit are shown below.
Allocated bytes
Unit Unit part number
Input Output
EX600-SEN3 / 4
(32 outputs)
0 4
SI unit
EX600-SEN3 / 4
(32 outputs)
(with diagnostic data)
4 4
EX600-DX□B
(8 inputs)
1 0
EX600-DX□C
(8 inputs)
1 0
EX600-DX□C1
(8 inputs)
(with open circuit detection)
1 0
EX600-DX□D
(16 inputs)
2 0
EX600-DX□E
(16 inputs)
2 0
Digital input unit
EX600-DX□F
(16 inputs)
2 0
EX600-DY□B
(8 outputs)
0 1
EX600-DY□E
(16 outputs)
0 2
Digital output unit
EX600-DY□F
(16 outputs)
0 2
EX600-DM□E
(8 inputs/8 outputs)
1 1
Digital I/O unit
EX600-DM□F
(8 inputs/8 outputs)
1 1
Analogue input Unit
EX600-AXA
(2 channels)
4
(2 bytes per channel)
0
Analogue output Unit
EX600-AYA
(2 channels)
0
4
(2 bytes per channel)
Analogue I/O Unit
EX600-AMB
(2/2 channels)
4
(2 bytes per channel)
4
(2 bytes per channel)
