<Example 3>
Unit 0
Unit 1
Unit 2
Unit 3
Unit 4
End plate
DX#B
Digital
input
1 byte
Input
DY#B
Digital
input
1 byte
Output
LAB1
IO-Link
Class A
44 byte
Input
44 byte
Output
LBB1
IO-Link
Class B
44 byte
Input
44 byte
Output
SEN3
SI unit
4 byte
Output
Valve
Input date: (Unit 0) Digital input unit (EX600-DX#B): 1 byte occupied
(Unit 2) IO-Link master unit (EX600-LAB1): 44 byte occupied
(Unit 3) IO-Link master unit (EX600-LBB1): 44 byte occupied
Output date: (Unit 1) Digital output unit (EX600-DY#B): 1 byte occupied
(Unit 2) IO-Link master unit (EX600-LAB1): 44 byte occupied
(Unit 3) IO-Link maser unit (EX600-LBB1): 44 byte occupied
(Unit 4) SI unit (EX600-SEN3-X80): 4 byte occupied
•When Diagnostic mode 0
Input data
Output data
Byte 0
DXB (Unit 3)
Input 0 to 7
Byte 0
DYB (Unit 1)
Output 0 to 7
Byte 1
LAB1 (Unit 1)
Process data
Byte 1
LAB1 (Unit 1)
Process data
:
:
Byte 44
Byte 44
Byte 45
LBB1 (Unit 3)
Process data
Byte 45
LBB1 (Unit 3)
Process data
:
:
Byte 88
Byte 88
Byte 89
Padding data (0)
Byte 89
SEN3 (Unit5)
Output 0 to 7
Byte 90
Byte 90
Output 8 to 15
Byte 91
Byte 91
Output 16 to 23
Byte 92
Byte 92
Output 24 to 31
Byte 93
Byte 93
Padding data
Total
90 byte
Total
94 byte
