-79-
No.EX※※-OMX1011
Data storage function
When the IO-Link port operation mode is set to "IOL_Manual", and in addition to this, when Validation &
Backup is set to "Type compatible, Device V1.1, Backup + Restore" or "Type compatible, Device V1.1,
Restore", the data storage function is available.
•Outline of backup or re-storage
The parameter set data in each IO-Link device can be stored (referred to as "backup") in the IO-Link master.
When the IO-Link device is replaced with a device with the same model, it is possible to set parameter data,
which has been backed up in the IO-Link master, can be transferred from the IO-Link master to the IO-Link
device (referred to as "restore").
•Condition of the backup / restore operation when the IO-Link communication starts up
The data storage function operation will be as follows based on the condition of the data storage of the
IO-Link master and parameter change of the IO-Link device.
Validation & Backup
set value
Condition
Data storage
operation
Data storage
function
Backup
requirement from
the device
Checksum of the data
storage and device
parameter
No Device Check
-
-
-
Cleared
Type compatible,
Device V1.0
-
-
-
Cleared
Type compatible,
Device V1.1
-
-
-
Cleared
Type compatible,
Device V1.1,
Backup + Restore
Data exits
Required
-
Backup
Data exits
No requirement
Not identical
Restore
Data exits
Required
Identical
Nothing occurs
No data
-
-
Backup
Type compatible,
Device V1.1,
Restore
Data exits
-
Not identical
Restore
Data exits
-
Identical
Nothing occurs
No data
-
-
Nothing occurs
Note 1) When the vendor ID or device ID are changed, the data storage will be cleared.
Note 2) When the IO-Link port operation mode is changed to a setting other than "IOL_Manual", Validation &
Backup values are automatically changed to "No Device Check". Therefore, the data storage is
cleared.
