Configuration format (EX600-AMB) Byte 7 to 31
Byte
Bit
EX600-AMB (32 byte)
Parameter
Setting value
7
0
(Ch0 out)
Output setting for communication fault
0: hold, 1: depend on fault value
1
(Ch1 out)
Output setting during communication Fault
0: hold, 1: depend on fault value
2
(Ch0 out)
Monitor upper limit value
0:disable, 1:enable
3
(Ch1 out)
Monitor upper limit value
0:disable, 1:enable
4
(Ch0 out)
Output setting for communication idling
0: hold, 1: depend on Idle value
5
(Ch1 out)
Output setting for communication idling
0: hold, 1: depend on Idle value
6
(Ch0 out)
Monitor lower limit value
0:disable, 1:enable
7
(Ch1 out)
Monitor lower limit value
0:disable, 1:enable
8..9
0..7
(Ch0 in) Monitor upper limit value
0 to 65535 (Low byte first)
10..11
0..7
(Ch0 in) Monitor lower limit value
0 to 65535 (Low byte first)
12..13
0..7
(Ch0 out) Upper limit value
0 to 65535 (Low byte first)
14..15
0..7
(Ch0 out) Lower limit value
0 to 65535 (Low byte first)
16..17
0..7
(Ch0 out) Fault value
0 to 65535 (Low byte first)
18..19
0..7
(Ch0 out) Idle value
0 to 65535 (Low byte first)
20..21
0..7
(Ch1 in) Monitor upper limit value
0 to 65535 (Low byte first)
22..23
0..7
(Ch1 in) Monitor lower limit value
0 to 65535 (Low byte first)
24..25
0..7
(Ch1 out) Upper limit value
0 to 65535 (Low byte first)
26..27
0..7
(Ch1 out) Lower limit value
0 to 65535 (Low byte first)
28..29
0..7
(Ch1 out) Fault value
0 to 65535 (Low byte first)
30..31
0..7
(Ch1 out) Idle value
0 to 65535 (Low byte first)
