-49-
No.EX※※-OMS0027
•Analogue input unit parameters
No. Parameter Definition Item Content
Default
setting
Parameter
setting range
Enable Generates an error.
○
1
The power
supply short
circuit
detection for
the input
device
Generates error
when the short
circuit of the power
supply for the input
device is detected.
Disable
Does not generate an
error.
Unit
-10..10 V
-5..5 V
-20..20 mA
0..10 V
0..5 V
1..5 V
0..20 mA
2
Analogue
input range
Sets the analogue
input device range.
4..20 mA
Selects the analogue
input range.
-10..10 V
Channel
Offset binary Offset binary.
○
Sign &
Magnitude
Signed binary.
3
Analogue
data format
Sets analogue data
type which is output
to PLC.
2s complement 2’s complement.
Unit
None None
2AVG 2 value average
○
4AVG 4 value average
4
Analogue
average filter
Sets analogue
filtering time.
8AVG 8 value average
Channel
Enable Generates an error.
○
5
Over range
detection
Generates error
when the input
value exceeds
0.5% of full span.
Disable
Does not generate an
error.
Unit
Enable Generates an error.
○
6
Under range
detection
Generates error
when the input
value falls below
0.5% of full span.
Disable
Does not generate an
error.
Unit
Enable Generates an error.

1
7
User setting
value upper
limit error
Generates error
when the input
value exceeds the
set value.
Disable
Does not generate an
error.
○
Channel
Enable Generates an error.

1
8
User setting
value lower
limit error
Generates error
when the input
value falls below
the set value.
Disable
Does not generate an
error.
○
Channel
1: Set value shall be set per analogue input range within settable range in the table below.
When the analogue input range is changed, check the set value and change it to an appropriate value.
