-50-
No.EX※※-OMS0027
Table. Settable range of user set value
Settable value range
Range
Lower limit Upper limit
-10..+10 V -10.50 to +10.45 V -10.45 to +10.50 V
-5..+5 V -5.25 to +5.22 V -5.22 to +5.25 V
-20..+20 mA -21.00 to +20.90 mA -20.90 to +21.00 mA
0..10 V 0.00 to +10.45 V +0.05 to +10.50 V
0..5 V 0.00 to +5.22 V +0.03 to +5.25 V
1..5 V +0.75 to +5.22 V +0.78 to +5.25 V
0..20 mA 0.00 to +20.90 mA +0.10 to +21.00 mA
4..20 mA +3.00 to +20.90 mA +3.10 to +21.00 mA
Correspondence table for user set upper or lower limit
Range Via E.O.

1
Via W.S.

2
Expected value
-10..+10 V
0 to 1050
32768 to 33818
0 to 1050
-0 to -1050
+0.00 to +10.50 V
-0.00 to -10.50 V
-5..+5 V
0 to 525
32768 to 33293
0 to 525
-0 to -525
+0.00 to +5.25 V
-0.00 to -5.25 V
-20..+20 mA
0 to 2100
32768 to 34868
0 to 2100
-0 to -2100
+0.00 to +21.00 mA
-0.00 to -21.00 mA
0..10 V 0 to 1050 0 to 1050 +0.00 to +10.50 V
0..5 V 0 to 525 0 to 525 +0.00 to +5.25 V
1..5 V 75 to 525 75 to 525 +0.75 to +5.25 V
0..20 mA 0 to 2100 0 to 2100 +0.00 to +21.00 mA
4..20 mA 300 to 2100 300 to 2100 +3.00 to +21.00 mA
1: Follow the methods below when assigning the user set upper and lower limit by E.O.
•Assigning positive value: Input the required data x 100 in decimal system.
Example: +10.50 V is assigned --- Assign 10.50 x 100 = 1050 by E.O.
•Assigning negative value: Convert the absolute value x 100 to be assigned in 16bit binary. Then, change the most significant bit to
"1" before inputting.
Example: -10.50 V is assigned --- Assign 10.50 x 100 = 1050  10000011010b  1000010000011010b  33818 by E.O.
2: When assigning the user set upper and lower limit by W.S., input the required data x 100 in decimal system.
