Details of I/O map of the IO-Link master unit
I/O map of the IO-Link master unit is described below. (Common for EX600-LAB1 and EX600-LBB1)
Reserved (fixed value: 0)
Reserved (fixed value: 0)
Input process data
Process data is assigned to each port based on the
process data mapping size setting
Output process data
Process data is assigned to each port based on the
process data mapping size setting
Reserved (fixed value: 0)
Reserved (fixed value: 0)
Reserved (fixed value: 0)
Reserved (fixed value: 0)
: X2: Input signal of Pin No.2
X4: Input signal of Pin No.4 when the IO-Link port operation mode is set to digital input mode (DI_C/Q)
Y4: Output signal of Pin No.4 when the IO-Link port operation mode is set to digital output mode (DO_C/Q)
: The process data size of the master unit port is fixed to 32 bytes input / 32 bytes output.
: When connecting to the EtherNet/IP compatible SI unit, 44 bytes are occupied for the master communication memory (the bytes in 38
bytes of the process data to which no I/O is assigned is fixed to 0).
•Port status (PQI) details
Connection device matching error
Process data mapping size error
1
0: Set size or less
1: Exceeding size
L+ short circuit or P24 short circuit
0: No short circuit
1: Short circuited
0: No short circuit
1: Short circuited
0: DS saved data error, no DS data
1: DS saved data is valid
Port communication status
0: Device not connected
1: Operation or preparation
Event
(Device or master event status)
0: No event or notification
1: Warning or Error
Received input process data
Valid (normal) / invalid (abnormal)
2
0: Invalid (abnormal)
1: Valid (normal)
1: An error is detected when the process data size of the actually connected device exceeds the size which is set in the process data
mapping.
2: Process data is maintained when the received input process data is abnormal (Process Data Invalid).
