-121-
No.EX※※-OMX1011
2-1. SMI_PortConfigList (acquires IO-Link master port parameter: Read)
[Request]
Data
Value
Notes
Service code
0x32
Class
0x90
Instance
0x01 to 09
Unit No. +1
Attribute
0x65 to 68
Port No. 1 to 4
Data[0]
0x80
Fixed value
Data[1]
0x00
Fixed value
[Response]
Data
Value
備考
Ack[0] to [3]
0xB2000000
When reading is succeeded: 0xB200000000
Data[0]
Port mode
0: Deactivated
1: IOL_Manual
2: IOL_Autostart
3: DI_C/Q
4: DQ_C/Q
Data[1]
Validation&Backup
0: No Device Check
1: Type compatible Device V1.0
2: Type compatible Device V1.1
3: Type compatible Device V1.1,Backup+Restore
4: Type compatible Device V1.1,Restore
Data[2]
I/Q behavior
(Pin2 at M12 Connector)
1:Digital input (For EX600-LAB1)
5:Power2 (For EX600-LBB1)
Data[3]
Port Cycle time
Port cycle type (Refer to page 78)
Data[4] to [5]
Vendor ID
Vendor ID for device comparison function
Data[6]
0x00
Reseved
Data[7] to [9]
Device ID
Vendor ID for device comparison function
