2-2. SMI_PortConfigList (acquires IO-Link master port parameter: Write)
[Request]
Data
Value
Notes
Service code
0x33
Service code
Class
0x90
Class
Instance
0x01 to 09
Instance, unit No.+1
Attribute
0x65..68
Port No. 1 to 4
Data[0]
0x80
Fixed value
Data[1]
0x00
Fixed value
Data[2]
Port mode
0: Deactivated
1: IOL_Manual
2: IOL_Autostart
3: DI_C/Q
4: DQ_C/Q
Data[3]
Validation&Backup
0: No Device Check
1: Type compatible Device V1.0
2: Type compatible Device V1.1
3: Type compatible Device V1.1,Backup+Restore
4: Type compatible Device V1.1,Restore
Data[4]
0x00
Fixed value
Data[5]
Port cycle time
Sets port cycle type (Refer to page 78)
Data[6]
Vendor ID [0] (MSB)
Sets vendor ID for device comparison
Data[7]
Vendor ID [1] (LSB)
Data[8]
0x00
Fixed value
Data[9]
Device ID [0] (MSB)
Sets vendor ID for device comparison
Data[10]
Device ID [1]
Data[11]
Device ID [2] (LSB)
[Response]
Data
Value
Notes
Ack[0] to [3]
0xB3000000
When writing is successful: 0xB300000000
