Configuration format (EX600-LAB1 / EX600-LBB1) Byte 0 to 5
Byte
Bit
EX600-LAB1 / EX600-LBB1 (46 byte)
Parameter
Setting value
0
0..3
Unit No.
0..8
4..7
Parameter type
1
1
0..7
Unit ID
EX600-LAB1:3B (Hex)
EX600-LBB1:3C (Hex)
Unit parameter
2
0
Monitor short circuit
0: disable, 1: enable
1
Reserved
0
2..3
Byte swap
0: direct, 1: 16 bit, 2: 32 bit, 3: all
4..7
Reserved
0
3
0..1
Fault output (IO-Link)
0: Clear / PD Out valid
1: Hold
2: Clear / PD Out invalid
2..3
Fault output (DO)
0: Clear
1: Hold
2: Force ON
4..5
Idle output (IO-Link)
0: Clear / PD Out valid
1: Hold
2: Clear / PD Out invalid
6..7
Idle output (DO)
0: Clear
1: Hold
2: Force ON
4
0..7
Process data mapping
Port1/Port2/Port3/Port4
(Input and Output)
0: 2 / 2 / 2 / 2
1: 4 / 4 / 4 / 4
2: 8 / 8 / 8 / 8
3: 16 / 16 / 2 / 2
4: 32 / 2 / 2 / 2
5
0
L+ control – Port 1
0: L+ ON, 1: L+ OFF
1
L+ control – Port 2
0: L+ ON, 1: L+ OFF
2
L+ control – Port 3
0: L+ ON, 1: L+ OFF
3
L+ control – Port 4
0: L+ ON, 1: L+ OFF
4..7
Reserved
0
