-106-
No.EX※※-OMX1011
Configuration format (EX600-LAB1 / EX600-LBB1) Byte 6 to 45
Byte
Bit
EX600-LAB1 / EX600-LBB1 (46 byte)
Parameter
Setting value
PortConfig – Port 1
6
0..7
PortMode
0: Deactivated
1: IOL_Manual
2: IOL_Autostart
3: DI_C/Q
4: DQ_C/Q
7
0..7
Validation&Backup
0: No Device Check
1: Type compatible Device V1.0
2: Type compatible Device V1.1
3: Type compatible Device V1.1,
Backup+Restore
4: Type compatible Device V1.1,Restore
8
0..7
Reserved
0
9
0..7
PortCycleTime
0: Automatic setting
1 to 3: 0.4 ms
4 to 63: 0.4 to 6.3 ms (by 0.1 ms)
64 to 127: 6.4 ms to 31.6 ms (by 0.4 ms)
128 to 191: 32 ms to 132.8 ms (by 1.6 ms)
192 to 255: 132.8 ms
10
0..7
VendorID[0] (MSB)
Vendor ID for validation comparison
11
0..7
VendorID[1] (LSB)
12
0..7
Reserved
0
13
0..7
DeviceID[0] (MSB)
Device ID for validation comparison
14
0..7
DeviceID[1]
15
0..7
DeviceID[2] (LSB)
PortConfig – Por t 2
16..25
0..7
See above
See above
PortConfig – Por t 3
26..35
0..7
See above
See above
PortConfig – Por t 4
36..45
0..7
See above
See above
