Specification
■Specifications
Model EX600-SEN3 EX600-SEN4
Protocol
EtherNet/IP
TM
(Conformance version : Composite 11)
Transmission medium
Standard EtherNet cable
(CAT5 or more, 100BASE-TX)
Transmission speed 10 / 100 Mbps
Transmission type Full duplex / Half duplex
Setting by SI unit switch :192.168.0 or 1.1～254
IP address setting range
Via DHCP server : Arbitrary address
Device information
Vendor ID: 7 (SMC Corporation)
Device type: 12 (Communication Adapter)
Product code: 203
Network topology
Star: Supported
Linear Bus: Supported
Ring (including DLR): Supported
EtherNet/IP QuickConnect
TM
Supported
Communication
Web server Supported
Current consumption 120 mA or less
Output type Source / PNP(negative common) Sink / NPN(positive common)
Number of solenoid valves 32 outputs
Applicable valve series
Solenoid valve with surge voltage suppressor of 24 VDC and 1.0 W or less
(manufactured by SMC)
Output setting during
communication fault
HOLD / CLEAR / Force ON
Valve output
Protection Short circuit protection
Enclosure IP67 (manifold assembly)

1
Operating temperature range -10 to 50
o
C
Storage temperature range -20 to 60
o
C
Operating humidity range 35 to 85% RH (no dew condition)
Withstand voltage 500 VAC for 1 minute between external terminals and FE
Insulation resistance 500 VDC, 10 MΩ or more between external terminals and FE
Vibration resistance
10 to 57 Hz: constant amplitude 0.75 mm p-p
57 to 150 Hz: constant acceleration 49 m/s
2
for 2 hours in each direction X, Y and Z respectively
(De-energized)
Environment
Impact resistance
147 m/s
2
3 times in each directions of X, Y and Z respectively
(De-energized)
Standard CE marking, UL (CSA), RoHS
Weight 300 g
1: All unused connectors must have a seal cap fitted.
